APPLICATION
Suitable for Paper/Labels and isolated paper/OPP/PET etc.
FEATURES
The machine is equipped with two sets of rewinding shaft with surface center rewinding to upgrade product smoothness.
Product tension can be wariably adjusted to suit various materials.
The machine is ruggedly constructed for maximum stability while in high speed operations. Equipped with a high performance controller for easy operation control.
The unwinding shaft can be adjusted forward/ backward and right/ left.
Alength counter provides convenient length setting. When requested a wide of optional accessories are available for more convenient and versatile operation.

MAIN TECHNICAL PARAMETERS:
MODEL
KH-B1000
KH-B1300
Unwind width
300-1000 mm
300-1300 mm
Unwind diameter
600 mm(MAX.)
Rewind width
20-1000 mm
20-1300 mm
Rewind diameter
600 mm(MAX.)
Inside diameter of core
3"
Machine speed
0-150 M/min

Due to machine development,above information may be changed at any time without prior notice.
The actual specification of machine accordings to the quotation.
