APPLICATION | Suitable for slitting and rewinding materials such as: non-woven cloth/paper for tubes/lamination films/adhesive tapes...etc. |
FEATURES | All controls for this machine are located in a conveniently positioned centralized control panel.The control panel offers outstanding control and features such major functions as: Two-step length counting with LED display/Tension setting/Montor speed meter and speed setting/Waste material switch. |
| This brake brings the machine to a complete stop. No tolerance is caused by running inertia. It providea complete uniformity and accuracy of tension control. |
| Top And Bottom Slitting Knives: The top slitting knives are adjustable,fully eliminating the problem of burrs,and the bottom knives are fixed. Such top and bottom knives design makes this unit especially suitable for slitting products with poor or uneven tension. The design creates a smooth,side surface finish to the product. |
| Pneumatic Unwinding Shaft: This 3"diameter,pneumatic shaft allows quick and easy loading of material,greatly improving productivity. |
