APPLICATION
Suitable for Glass paper/PET/OPP/PE/PVC.
FEATURES
The unwinding shaft can be adjusted forwards/backwards and right/left.
The unwinding and rewinding shafts feature horizontal swivelling for convenient,fast material loading and unloading,which require only a single operator to accomplish.
The machine is equipped with a high perforance controller for easy operation control. High speed slitting performance creates high productivity.
When requested,a wide range of optional accessories are available for more convenient and versatile operations.

MAIN TECHNICAL PARAMETERS:
MODEL
KH-A1000
KH-A1300
Unwind width
200-1000 mm
200-1300 mm
Unwind diameter
600 mm(MAX.)
Rewind width
50-1000 mm
50-1300 mm
Rewind diameter
420 mm(MAX.)
Inside diameter of core
3"
Machine speed
0-200 M/min

Due to machine development,above information may be changed at any time without prior notice.
The actual specification of machine accordings to the quotation.
