APPLICATION
Suitble for coating Kraft paper/trademark paper/metal foil plastic film/natural textiles/chemical fibre fabrics/non-woven cloth/carpet
/paper-plate etc.
FEATURES
An AC converter control is used for both speed and quantity of glue feeding,for which both automatic synchronous tracking and manusl control are available.
The advanced PID control is used for the temperature control system and the error is with in.
The expansion of the applicable range of the basic materials is made available with the cooling device.
The adhesion-proof coated layer with the glue-melting box effectively prevent the thermal-melting glue against being carbonized.

MAIN TECHNICAL PARAMETERS:
Spreading width500mm/1000mm/1300mm/1600mm
Spreading qunty15-20 g
Spreading speed50 M/min
Diameter of roll-placing1000 mm
Diameter of roll wind-up700 mm
Roll-placer2 sets
Wrap-up1 sets
Deviation correctoroptional
Cachine-assembly power12 kw
Maximum Temp.230°C

Due to machine development,above information may be changed at any time without prior notice.
The actual specification of machine accordings to the quotation.
