APPLICATION
Suitable for producing adhesive tape,such as:
BOPP tape/Double-side tape/Krafe paper tape/Label sticker/Foam tape/ Cloth tape/Polyester and Release paper.
FEATURES
Special designs,suitable for various kind of materials.
Auto tension control.
Auto temperarure control to suit refresh materials.
Spcial designs for heating system,high efficiency.
According to different types to design different coating method.

MAIN TECHNICAL PARAMETERS:
MODEL
GPC-500
GPC-1000
GPC-1300
GPC-1600
Vaild width
500 mm
1000 mm

1300 mm

1600 mm
Mechanical speed
5-30 M/min
5-80 M/min
15-150 M/min
15-150 M/min
Coating average degree
±0.025 mm
Rewinding Epc
±3 mm
Mechanical power
5-25 HP
20-45 HP
30-80 HP
40-100 HP
Oven length
According to the customer the request proceeds the design
Heating
Steam/Hot blast/Heat conductive oil/Electricity

Due to machine development,above information may be changed at any time without prior notice.
The actual specification of machine accordings to the quotation.
