APPLICATION
Suitable for OPP adhesive tape/glass paper tape.
FEATURES
Centralized control panel:All operation controls. For this machine are centralized in a control panel.
Three-step length setting:This length setting provides extremely smooth rewinding operation to gives accurate rewinding length.
Automatic shaft change:Once the rewinding operation is accomplished,the machine will automatically perform shaft changes for convenient and wfficient operations.
Labeling indication:This plate is attached with a reference line for labeling instructions.

MAIN TECHNICAL PARAMETERS:
Valid width
1350 mm
Max. diameter of materials
600 mm
Slitting width
12-1280 mm
Inside diameter of paper core
76.2 mm
Diameter of rewinding
4 Shafts rewind
76.2-150 mm
2 Shafts rewind
76.2-300 mm
Blade
0.2 x 22 x 60 mm
Machine speed
0-180 M/min
Main motor
5 HP

Due to machine development,above information may be changed at any time without prior notice.
The actual specification of machine accordings to the quotation.
