APPLICATION
Suitable for double-side tape/ Kraft paper tape/ Masking tape/ Foam tape/ PVC and Cloth tape.
FEATURES
Combined function of rewinding and cutting,with manifold usage that can save investment.
Scratching cutting and manual feeding of cutters with smooth cutting section.
Equipped with cutting eidth gauge for quick and stable positioning.
Main shaft adopted with stepless adjusting electro-magnetic slip,motor to suit cutting requirement of different materials.
Equipped with length counter that can automatically calcullate the rewinding length and stall the machine when necessary and this facilitate operation.
The smooth roller is coated with teflon to fully prevent glue adhering.
The curved rubber roller,facilitae adjustment,surety high quality of the products.

MAIN TECHNICAL PARAMETERS:
Vaild width
1300 mm
Cutting width3-1300 mm
Inside diameter of paper core32-76.2 mm
Maximum diameter of cutting150 mm
Motor3 HP

Due to machine development,above information may be changed at any time without prior notice.
The actual specification of machine accordings to the quotation.
